The KECES S4 Stereo Preamplifier is a versatile, high-end audiophile unit. It stands out for its built-in DS Audio optical equalizer, an excellent MM/MC phono stage, and a Class-A balanced headphone amplifier. Delivers an incredibly transparent, warm, and dynamic sound that rivals much more expensive equipment
-Single-ended, zero feedback circuit topology and demanding pure Class A operation and removing the need for a phase splitter.
- Fully symmetrical construction and offer a wide range of symmetrical (XLR) and asymmetrical (RCA) inputs and corresponding outputs.
-The pre-amplifier circuit boards are of symmetrical double-mono construction
-The elaborate volume regulator is created by an R-2R network that has the same impedance at 128 possible, logarithmically tuned levels and guarantees an extremely good synchronism down to the lowest volumes.
-The new design uses low noise toroidal transformer in external supply.
-Build in DS audio EQ and MC/MM phono.
-Build in high-quality headphone amplifier.
-All-metal infra-red remote control handset.
-The components and materials employed are uniformly of top quality.
Keces S4 Stereo Preamplifier
Input MM/MC*1 / Optical*1 / RCA*1 / XLR*2
Input Impedance MC: 56/100/220/470/47K
MM: 47K
OPT: More than 10K
RCA/XLR: 170KOutput RCA*2 / XLR*1 / Headphone XLR-4pin
Total harmonic distortion (THD+N) MM<0.02%, MC<0.05%, OPT<0.04%
RCA<0.0015%, XLR<0.0015%S/N R MM: 78dB A-Weighted
MC: 70dB A-weighted
Optical: 75dB A-weighted
RCA: 110dB A-weighted
XLR: 110dB A-weightedGain MM: 52dB / MC: 72dB / OPT: 32dB
RCA/XLR: 20dBPower Requirement Standby: 0.5 Watt
Maximum: 90 WattsCasing All Aluminum
Dimension (WxDxH) 300x279x66mm*2
Weight Net Weight 4.5KG(Power) / 3.5KG(Pre)
Shipping Weight 10KG
